| MODEL NO. | INPUT VOLTAGE (V) | POWER (W) | OUTPUT CURRENT (mA) | LUMEN (lm) | COLOUR TEMPERATURE (K) | CRI | R9 | BEAM ANGLE (°) | FITTING COLOUR | CARTON QUANTITY |
|---|---|---|---|---|---|---|---|---|---|---|
| GDL956 CW WH | 230 | 25 | 700 | 2400 | 4000 | >90 | >75 | 60 | White | 12 |
| GDL958 CW WH | 230 | 50 | 1350 | 4800 | 4000 | >90 | >75 | 60 | White | 8 |
| GDL956 CW BK | 230 | 25 | 700 | 2400 | 4000 | >90 | >75 | 60 | White | 12 |
| GDL958 CW BK | 230 | 50 | 1350 | 4800 | 4000 | >90 | >75 | 60 | White | 8 |
| GDL956 CW WH SQ | 230 | 25 | 700 | 2400 | 4000 | >90 | >75 | 60 | White | 12 |
| GDL958 CW WH SQ | 230 | 50 | 1350 | 4800 | 4000 | >90 | >75 | 60 | White | 8 |
| GDL956 CW BK SQ | 230 | 25 | 700 | 2400 | 4000 | >90 | >75 | 60 | White | 12 |
| GDL958 CW BK SQ | 230 | 50 | 1350 | 4800 | 4000 | >90 | >75 | 60 | White | 8 |
OPTIONS
• DIMMING:
-Analogue dimming (Trailing edge, 1~10V)
-Digital dimming (DSI, DALI)
| MODEL | GDL956 CW WH, GDL958 CW WH, GDL956 CW WH SQ, GDL958 CW WH SQ, GDL956 CW BK, GDL958 CW BK, GDL956 CW BK SQ, GDL958 CW BK SQ |
|---|---|
| INSTALLATION | RECESSED |
| INPUT | 230V |
| WATTAGE (W) | 25, 50 |
| LUMEN | 2400, 4800 |
| COLOUR TEMPERATURE | COOL WHITE |
| BEAM ANGLE (°) | 60 |
| FITTING COLOUR | WHITE |
| DIMMABLE | NO |
| CRI (>) | 90 |
| IP RATING | IP54 |
