MATRIX MINI SPOT
- Die-cast aluminium body
- Powder coated finish
- Colour matching (SDCM): 3 MacAdam steps
- Constant current LED driver included
- IP20
- IC-F
- UGR<19
- LED lifespan: 50000 Hours @L70, Ta 25°C
- Ta:-20°C to + 40°C
- 5 year warranty
MATRIX MINI SPOT
MATRIX MINI SPOT
x
Product Description
| LIGHT IMAGE | MODEL | INPUT | POWER | LUMEN | COLOUR TEMPERATURE | CRI | BEAM ANGLE | DIMENSIONS(Ø×H) | CUT OUT SIZE(Ø) | FITTING COLOUR |
|---|---|---|---|---|---|---|---|---|---|---|
 |
GFGL05 WH | 230V | 13W | 850lm | 3000K | >90 | 40° | 150X45X60mm | 142X37mm | White |
 |
GFGL05 BK | 230V | 13W | 850lm | 3000K | >90 | 40° | 150X45X60mm | 142X37mm | Black |
| LIGHT IMAGE | MODEL | INPUT | POWER | LUMEN | COLOUR TEMPERATURE |
CRI | BEAM ANGLE | DIMENSIONS(Ø×H) | CUT OUT SIZE(Ø) | FITTING COLOUR |
|---|---|---|---|---|---|---|---|---|---|---|
 |
GFWW05 WH | 230V | 13W | 550lm | 3000K | >90 | 40° | 150X45X60mm | 142X37mm | White |
 |
GFWW05 BK | 230V | 13W | 550lm | 3000K | >90 | 40° | 150X45X60mm | 142X37mm | Black |
| LIGHT IMAGE | MODEL | INPUT | POWER | LUMEN | COLOUR TEMPERATURE |
CRI | BEAM ANGLE | DIMENSIONS(Ø×H) | CUT OUT SIZE(Ø) | FITTING COLOUR |
|---|---|---|---|---|---|---|---|---|---|---|
 |
GFRG05 WH | 230V | 13W | 850lm | 3000K | >90 | 40° | 168.5X70X60mm | 160X52mm | White |
 |
GFRG05 BK | 230V | 13W | 850lm | 3000K | >90 | 40° | 168.5X70X60mm | 160X52mm | Black |
| LIGHT IMAGE | MODEL | INPUT | POWER | LUMEN | COLOUR TEMPERATURE | CRI | BEAM ANGLE | DIMENSIONS(Ø×H) | CUT OUT SIZE(Ø) | FITTING COLOUR |
|---|---|---|---|---|---|---|---|---|---|---|
 |
GFGL03 WH | 230V | 11W | 650lm | 3000K | >90 | 40°+30°(spot light) | 150X45X60mm | 142X37mm | White |
 |
GFGL03 BK | 230V | 13W | 550lm | 3000K | >90 | 40°+30°(spot light) | 150X45X60mm | 142X37mm | Black |
| LIGHT IMAGE | MODEL | INPUT | POWER | LUMEN | COLOUR TEMPERATURE | CRI | BEAM ANGLE | DIMENSIONS(Ø×H) | FITTING COLOUR |
|---|---|---|---|---|---|---|---|---|---|
 |
GMGL05 WH | 230V | 13W | 850lm | 3000K | >90 | 40° | 140X35.3X60mm | White |
 |
GMGL05 BK | 230V | 13W | 850lm | 3000K | >90 | 40° | 140X35.3X60mm | Black |
GFGL05
GFWW05
GFRG05
GFGL03
GMGL05
Product Specification
| MODEL | GFGL05 WH, GFGL05 BK, GFWW05 WH, GFWW05 BK, GFRG05 WH, GFRG05 BK, GFGL03-FSL01 WH, GFGL03-FSL01 BK, GMGL05 WH, GMGL05 BK |
|---|---|
| COLOR | WHITE,BLACK |
| CUT OUT SIZE (Ø mm) | 142×37, 160×52 |
| INSTALLATION | RECESSED, SURFACE MOUNTED |
| INPUT | 230V |
| WATTAGE (W) | 11, 13 |
| LUMEN | 550, 650, 850 |
| COLOUR TEMPERATURE | WARM WHITE |
| BEAM ANGLE (°) | 40 |
| FITTING COLOUR | BLACK, WHITE |
| DIMMABLE | NO |
| CRI (>) | 90 |
| IP RATING | IP20 |
| FLEX&PLUG | Flex |
| IC RATING | IC-F |
| DOUBLE INSULATION | YES |
| LIGHT DIRECTION | FIXED, TILTABLE |
| GLARE CONTROL |
