MINI
CONSTANT CURRENT LED DRIVER
x
Product Description
| MODEL NO. |
INPUT VOLTAGE
(V)
|
MAX OUTPUT POWER
(W)
|
OUTPUT CURRENT
(mA)
|
OUTPUT VOLTAGE
(V)
|
POWER FACTOR | Ta (°C) |
|---|---|---|---|---|---|---|
| GMINI350mA/4W | 230V | 4 | 350 | 6~12 | 0.6 | -20 to +50 |
| GMINI350mA/10W | 230V | 10 | 350 | 14~24 | 0.9 | -20 to +50 |
| GMINI500mA/4W | 230V | 4 | 500 | 2~8 | 0.4 | -20 to +50 |
| GMINI500mA/12W | 230V | 12 | 500 | 8~24 | 0.95 | -20 to +50 |
Product Specification
| MODEL | GMINI350mA/4W, GMINI350mA/10W, GMINI500mA/4W, GMINI500mA/12W |
|---|---|
| IP RATING | IP65 |
| WATTAGE (W) | 10, 12, 4 |
